12VDC (8-16v) 30A Power Supply

SKU: EC-PWRSP

$168.00

FEATURES:
Two DC power outputs, up to 30 amps total
Output voltage adjustable 12-18V
Large LCD indicates voltage and current amperes output
Two USB ports, 5 volts, 1000mA total for MP3 player, avionics & cell phone
Smart cooling fan
Over temperature protection
Over loading protection
Short circuit protection
SPECIFICATIONS:
Voltage…………………………………………………………………100-240V AC
Input AC Frequency…………………………………………………50-60Hz
Output Voltage………………………………………………………12-18Vdc +/- 0.5V
Output Current………………………………………………………30A +/- 1A
Current Overload Protection………………………………………< 31A 500ms
Input Fuse………………………………………………………………10A Fuse
LCD Display……………………………………………………………Voltage Precision 0.3V
LCD Display……………………………………………………………Current Precision 0.3A
Output Voltage Ripple………………………………………………<150mv
Power Efficiency………………………………………………………89%
Power Factor……………………………………………………………> 0.98
Over Temperature Protection………………………………………< 65℃
Cooling Method……………………………………………….………Cooling Fan
Operating Temperature…………………………………….………0-40℃
Operating Humidity…………………………………………………0-90%
Dimensions (L*W*H)…………………………………………………218 x 139 x 59.5mm
Net weight…………………………………………………….………1.62kg

Additional Information

Weight 4.6
Dimensions 13 x 7.5 x 4 in
